RD-2220 Elite II J-Bend Front Road Hub

Part #: 371897

HUB FT OR8 RD2220 ELITE II QR 20x100 SB BK NO SKEWER

The Elite Series II is Origin8`s flagship line of high-performance road hubs
Rear hubs feature 36T Ratchet Drive System for 10° engagement
Shimano, SRAM, and Campagnolo cassette body options
Straight pull and J-bend spoke options
Premium sealed bearings
Skewers not included

Use	Spoke Count	Spacing / Axle	Material	Color	Brake Type	OLD	PCD-L	PCD-R	LTF-L	LTF-R	CTF-L	CTF-R	Bearing Type	Axle Length	Hole Diameter
FT	20H	QR	AL6061	Blk	Rim	100	31	31	17	17	33	33	Sealed	108	2.5

Flux Stem

Part #: 58811

STEM OR8 FLUX CNC 90x31.8x28.6 +/-5d BK

Road or Mountain compatible
Full CNC machined AL6061-T6 alloy construction
4-bolt front loading one-piece faceplate design
ISO-Mountain safety certified

Type	Fork Dia	Length	Bar Clamp	Angle	Color	Material	Stack Height
Road/MTB	1-1/8"	90	31.8	+/- 5°	Black	AL6061-T6	40

Fury OS III

Part #: 34949

HBAR OR8 MTB ALY RISE FURY OS 35x800x35BK

AL7050-T6 tubular alloy construction
35mm oversized clamp diameter
800mm width
7°/8° back sweep (Depending on rise dimension)
5° upsweep
ISO-Mountain safety certified
290-335g (Depending on rise dimension)

Clamp Size	Width / Length	Rise / Reach	Upsweep / Drop	Back Sweep / Bend	Color	Type	Material
35mm	800mm	35mm	5°	8°	Black	Mountain Riser	AL7050

Fury OS II

Part #: 34948

HBAR OR8 MTB ALY RISE FURY OS 35x800x25BK

AL7050-T6 tubular alloy construction
35mm oversized clamp diameter
800mm width
7°/8° back sweep (Depending on rise dimension)
5° upsweep
ISO-Mountain safety certified
290-335g (Depending on rise dimension)

Clamp Size	Width / Length	Rise / Reach	Upsweep / Drop	Back Sweep / Bend	Color	Type	Material
35mm	800mm	25mm	5°	7°	Black	Mountain Riser	AL7050

Fury OS I

Part #: 34947

HBAR OR8 MTB ALY RISE FURY OS 35x800x15BK

AL7050-T6 tubular alloy construction
35mm oversized clamp diameter
800mm width
7°/8° back sweep (Depending on rise dimension)
5° upsweep
ISO-Mountain safety certified
290-335g (Depending on rise dimension)

Clamp Size	Width / Length	Rise / Reach	Upsweep / Drop	Back Sweep / Bend	Color	Type	Material
35mm	800mm	15mm	5°	7°	Black	Mountain Riser	AL7050

Flux MTB Stem

Part #: 58807

STEM OR8 FLUX CNC 55x31.8x28.6 0d BK

Full CNC machined AL6061-T6 alloy construction
4-bolt front loading faceplate design
ISO-Mountain safety certified

Type	Fork Dia	Length	Bar Clamp	Angle	Color	Material	Stack Height
MTB	1-1/8"	55	31.8	0°	Black	AL6061	35

Flux MTB Stem

Part #: 58806

STEM OR8 FLUX CNC 45x31.8x28.6 0d BK

Full CNC machined AL6061-T6 alloy construction
4-bolt front loading faceplate design
ISO-Mountain safety certified

Type	Fork Dia	Length	Bar Clamp	Angle	Color	Material	Stack Height
MTB	1-1/8"	45	31.8	0°	Black	AL6061	35

Revolvr BB386/BB392 Thread-Together Bottom Bracket

Part #: 211963

BB SET OR8 REVOLVR BB386 TO FIT DUB THREAD TOGETHER SB BK

Thread-together bottom brackets provide a secure and stable shell interface for smoother operation and extended bearing life
Hybrid AL6061/Nylon fiber cups for a superior fit and noise-free operation
Low-friction dual seals protect the bearings from harmful contaminants
Sealed premium bearings are both serviceable and replaceable
Designed for installing Shimano HTII 24mm, SRAM GXP 22/24mm, or DUB spindle cranks into BB386 frames without the need for adapters
Origin8 Nylon composite BB tools are recommended to avoid the possibility of damaging the cups

Shell	Interface	Spindle Type	Cup Material	Weight
86.5/92mm x 46mm	BB386/BB392	SRAM DUB 28.99mm	AL6061/Nylon Fiber	135g

Flux MTB Stem

Part #: 58805

STEM OR8 FLUX CNC 35x31.8x28.6 0d BK

Full CNC machined AL6061-T6 alloy construction
4-bolt front loading faceplate design
ISO-Mountain safety certified

Type	Fork Dia	Length	Bar Clamp	Angle	Color	Material	Stack Height
MTB	1-1/8"	35	31.8	0°	Black	AL6061	35

Everland All-Road Platform

Part #: 410429

PEDALS OR8 EVERLAND ALL-ROAD 9/16 BK/SL

Streamlined design is ideal for Road and All-Road/Gravel applications
Extruded and CNC machined AL6061 alloy pedal body
CNC machined 9/16" Cr-Mo spindle
LSL sleeve bushing and sealed bearing
75mm x 106mm x 13mm concave platform
6 replaceable pins per side
310g pair

Size	Bearing	Color	Material	Platform Size	Style	Search Color
9/16"	1 Sealed and 1 Sleeve	Black	AL6061	75x106x13mm	Platform Pedals	Black

Throne Road

Part #: 50773

SADDLE OR8 THRONE XL ROAD BK

Performance saddle with Air Foam padding for enhanced comfort and support
Short and wide saddle shape provides ample sit bone support for both men and women
Nylon fiber injected base for longevity and all-day riding efficiency
Soft-touch, posi-grip cover with high gloss graphics offers superior control
Suspended rail design provides flexibility and shock absorption for greater comfort
Ergonomic recessed channel center section to relieve pressure on soft tissue areas

Use	Rail	Padding	Color	Size (LxW)	Weight	Frame Material	Gender
Road	CrN-Ti Alloy	Air Foam	Black	244mm x 158mm	284g	Nylon Fiber	Unisex

Mini Tri Clip-On Bars

Part #: 33967

HBAR OR8 TRI ALY MINI CLIP-ON BLK

AL6061-T6 tubular alloy construction
Independent bar angle adjustment
Adjustable 110mm x Ø22.2mm hand extensions
Fits 25.4mm, 26.0mm, and 31.8mm handlebars
Cannot mount shifters on to bar ends
Does not include armrests
Not recommended for use with carbon handlebars

Clamp Size	Width / Length	Color	Type	Material
25.4mm - 31.8mm	110mm x Ø22.2mm	Black	Aero Bars	AL6061

Revolvr BB30 Outboard Thread-Together Bottom Bracket

Part #: 211568

BB SET OR8 REVOLVR BB30 TO FIT DUB OUTBOARD THREAD TOGETHER SB BK

Thread-together bottom brackets provide a secure and stable shell interface for smoother operation and extended bearing life
Hybrid AL6061/Nylon fiber cups for a superior fit and noise-free operation
Low-friction dual seals protect the bearings from harmful contaminants
Sealed premium bearings are both serviceable and replaceable
Designed for installing Sram DUB 28.99mm spindle cranks into BB30 frames

Shell	Interface	Spindle Type	Cup Material	Weight	Color
68/73mm x 42mm	BB30	SRAM DUB 28.99mm	AL6061/Nylon Fiber	120g	Black

Everland Adventure

Part #: 34852

HBAR OR8 GX ALY EVERLAND ADVENTURE 31.8x610 BK

Gravel adventure/touring inspired off-road drop handlebar
Double butted AL6061-T6 construction
610mm drop width / 460mm top width
35º flared drops for improved comfort, control, power, and stability
Flattened top section for enhanced comfort
Offers multiple hand positions to address long miles and varied terrain
Accepts bar end shifters
ISO-Road/Mountain safety certified

Clamp Size	Width / Length	Rise / Reach	Upsweep / Drop	Color	Type	Material
31.8mm	610mm	95mm	90mm	Black	Off-Road Drop	AL6061

Supercell

Part #: 590712

TIRE OR8 SUPERCELL 26x4.0 FOLD BK/BK

Wide fast rolling street style tread that extends all the way to the sidewall
Large channels and siping help evacuate water quickly and provide a plush smooth ride
Wrap around tread extends into the side wall for predictable and grippy turning even when running low PSI
Available in a supple dual compound 120 TPI casing or a more puncture resistant firm 30 TPI option

Style	Size	ISO	Bead	Tread/SW	PSI	Weight	TPI	Reflective Sidewall	Tread Style
Standard	26x4.0	559	Fold	Bk/Blk	20	1375	120	No	Smooth

Tsunami

Part #: 590710

TIRE OR8 TSUNAMI 26x4.0 FOLD BK/BK

Well-spaced and siped lugs help keep rolling resistance at a minimum even while running low air pressure
Large siping of lugs provides additional grip in sand, snow and other unfavorable conditions
Staggered corner lugs provide a stable and predictable turning platform
Available in 120 TPI for a supple, obstacle conforming tire, or 30 TPI for a durable yet forgiving casing

Style	Size	ISO	Bead	Tread/SW	PSI	Weight	TPI	Reflective Sidewall	Tread Style
Standard	26x4.0	559	Fold	Bk/Blk	20	1175	120	No	Knobby

SpeedCheck Two-Piece Floating Rotor

Part #: 120201

BRAKE PART OR8 DISC ROTOR SPDCK 2p 6B 203mm BK

Two-piece design with alloy carrier and stainless steel braking surface
Alloy carrier allows for increased dissipation of heat caused by braking
Independent spring pin fasteners provide a true "floating rotor" design
Interlocking dovetail feature eliminates brake load on pins
6-Bolt mounting pattern
Torx bolts included

Size	Color	Type
203mm	Black	6B

Holdfast Oval Direct 1x Chainring GXP

Part #: 210315

CHAINRING OR8 HOLDFAST OVAL DIRECT FOR GXP 32T 10/11/12s BK

Narrow/Wide tooth design for chain retention on 1x systems
Oval shape for increased power and efficiency
13% ovality and 115º clocking
10, 11, or 12 speed compatible
Mud clearing channels
CNC AL7075-T6 Swiss Alloy

Mount Compatibility	Teeth	Type	Material	Spec	Color	Chain Compatibility	Tooth Type
Direct Mount	32T	1x	AL7075	GXP	Black	10/11/12sp	Narrow/Wide

Holdfast Oval 1x Chainring 104mm BCD

Part #: 210313

CHAINRING OR8 HOLDFAST OVAL 104mm 32T 10/11/12s 4B BK

Narrow/Wide tooth design for chain retention on 1x systems
Oval shape for increased power and efficiency
13% ovality and 115º clocking
10, 11, or 12 speed compatible
Mud clearing channels
CNC AL7075 Swiss Alloy

Mount Compatibility	Teeth	Type	Material	Color	Chain Compatibility	Tooth Type
104mm 4-bolt	32T	1x	7075AL	Black	10/11/12sp	Narrow/Wide

Fury III

Part #: 34473

HBAR OR8 MTB ALY RISE FURY 31.8x800x30 BK

AL7050-T6 tubular alloy construction
31.8mm clamp diameter
800mm width
7° back sweep
3°/4° upsweep (Depending on rise dimension)
ISO-Mountain safety certified
310-350g (Depending on rise dimension)

Clamp Size	Width / Length	Rise / Reach	Upsweep / Drop	Back Sweep / Bend	Color	Type	Material
31.8mm	800mm	30mm	3°	7°	Black	Mountain Riser	AL7050

Holdfast 1x Chainring 104mm BCD

Part #: 210243

CHAINRING OR8 HOLDFAST 104mm 30T 10/11/12s 4B BK

Narrow/Wide tooth design for chain retention on 1x systems
CNC machined AL7075-T6 Swiss made alloy
10, 11, or 12 speed compatible
Mud clearing channels

Mount Compatibility	Teeth	Type	Material	Color	Chain Compatibility	Tooth Type
104mm 4-bolt	30T	1x	AL7075	Black	10/11/12sp	Narrow/Wide

Fury II

Part #: 34472

HBAR OR8 MTB ALY RISE FURY 31.8x800x20 BK

AL7050-T6 tubular alloy construction
31.8mm clamp diameter
800mm width
7° back sweep
3°/4° upsweep (Depending on rise dimension)
ISO-Mountain safety certified
310-350g (Depending on rise dimension)

Clamp Size	Width / Length	Rise / Reach	Upsweep / Drop	Back Sweep / Bend	Color	Type	Material
31.8mm	800mm	20mm	3°	7°	Black	Mountain Riser	AL7050

AT-PRO80-UL

Part #: 48878

RIM OR8 26 559x74 AT-PRO80-UL 32/64 BK/NMSW PV

Size	Brand	Model	ISO	Width ID	Width OD	Profile	Wall	Side	Color	Hole Count	Valve	Weight	ERD	Tire Compatibility	Search Color	Spoke Size
26in	Origin8	AT-PRO80-UL	559	74	80	24.5	Sgl	NMSW	Black	32	PV	1061g	536	Tube Only	Black	14g

Classic Sport 3/32

Part #: 22942

CRANKSET OR8 C-SPORT SINGLE 170x46 3/32SL SQ

Single speed crankset
Forged alloy crankarms
Includes machined alloy chainring
45mm chainline with 113mm BB
Does not include square taper BB
Weights do not include BB
** Not recommended for fixed gear riding

Length / Teeth	Spindle Type	Color	Bolt Pattern	Weight	Speed
170x46	113 SQR JIS	SIL	130x5B	640g	1

Bolt Alloy MTB XC

Part #: 470815

RIM OR8 29 622x25x22 BOLT ALLOY MTB TBLS 32 DISC BK (K)

AL6061-T6 alloy construction
Post-production anodized in a sanded gloss black finish
Eyeletted spoke holes
Tubeless ready
Disc brake only
Sleeved joint
ISO-Mountain certified

Size	Brand	Model	ISO	Width ID	Width OD	Profile	Wall	Side	Color	Hole Count	Valve	Weight	ERD	Tire Compatibility	Search Color	Spoke Size
29	Origin8	Bolt Alloy MTB XC	622	25	30	21.5	Dbl	DISC	Black	32	PV	485g	594.4	Tubeless Compatible	Black	14g

Mountain Double Clipless

Part #: 41960

PEDALS OR8 MTB DBL CLPLS 9/16 BK/GY

Forged AL6061 alloy pedal body
CNC machined chromoly spindle
2 LSL sleeve bushings
Adjustable tension
SPD compatible (6° float) cleats included
80mm x 49mm
275g pair

Size	Bearing	Color	Cleat Type	Style
9/16"	2 Sleeve	Gloss Black	SPD	Double Sided

SpeedCheck Two-Piece Floating Rotor

Part #: 120200

BRAKE PART OR8 DISC ROTOR SPDCK 2p 6B 180mm BK

Two-piece design with alloy carrier and stainless steel braking surface
Alloy carrier allows for increased dissipation of heat caused by braking
Independent spring pin fasteners provide a true "floating rotor" design
Interlocking dovetail feature eliminates brake load on pins
6-Bolt mounting pattern
Torx bolts included

Size	Color	Type
180mm	Black	6B

Revolvr BB90/95 OS Thread-Together Bottom Bracket

Part #: 211710

BB SET OR8 REVOLVR BB90/95 TO SHI OS THREAD TOGETHER SB BK

Replaces standard BB90/95 press in bearings commonly found on Trek bicycles with a solid, unified thread-together bottom bracket interface
Thread-together bottom brackets provide a secure and stable shell interface for smoother operation and extended bearing life
OS versions are designed for use in frames with worn-out, oversized bottom bracket shells
Low-friction dual seals protect the bearings from harmful contaminants
Sealed premium bearings are serviceable
Models available for both Shimano HTII 24mm and SRAM GXP 22/24mm spindles
Requires a special tool for installation (J&B# 610756)

Shell	Interface	Spindle Type	Cup Material	Color
90.5/95.5mm x 37.1~37.2mm	BB90/95	Shimano HTII 24mm	AL6061	Black

Revolvr BB86/92 OS Thread-Together Bottom Bracket

Part #: 211707

BB SET OR8 REVOLVR BB86/92 TO SHI OS THREAD TOGETHER SB BK

Thread-together bottom brackets provide a secure and stable shell interface for smoother operation and extended bearing life
OS versions are designed for use in frames with worn-out, oversized bottom bracket shells
Hybrid AL6061/Nylon fiber cups for a superior fit and noise free operation
Low-friction dual seals protect the bearings from harmful contaminants
Sealed premium bearings are both serviceable and replaceable
Models available for both Shimano HTII 24mm and SRAM GXP 22/24mm spindles
Replaces all standard BB86/92 press-fit bottom brackets
Origin8 Nylon composite BB tools are recommended to avoid the possibility of damaging the cups

Shell	Interface	Spindle Type	Cup Material	Weight
86-92mm x 41~41.1mm	BB86/BB92	Shimano HTII 24mm	AL6061/Nylon Fiber	103g

Revolvr BB86/92 Press-Fit Bottom Bracket

Part #: 211059

BB SET OR8 REVOLVR BB86/92 TO BB30 WIDE/BB386 SB BK

Precision machined AL6061 cups for a superior fit and noise-free operation
Low-friction dual seals protect the bearings from harmful contaminants
Sealed dual-row premium flanged bearings
Designed for installing BB30 Wide, BB386, BB392, and other 30mm spindle cranks into BB86/92 frames*
*For use with 30mm diameter cranks with a spindle length of at least 104mm

Shell	Interface	Spindle Type	Cup Material	Weight
86-92mm x 41mm	BB86/BB92	BB30 Wide/BB386 30mm	AL6061	80g

Revolvr BB386 Thread-Together Bottom Bracket

Part #: 211058

BB SET OR8 REVOLVR BB386 TO FIT GXP THREAD TOGETHER SB BK

Thread-together bottom brackets provide a secure and stable shell interface for smoother operation and extended bearing life
Hybrid AL6061/Nylon fiber cups for a superior fit and noise-free operation
Low-friction dual seals protect the bearings from harmful contaminants
Sealed premium bearings are both serviceable and replaceable
Designed for installing Shimano HTII 24mm, SRAM GXP 22/24mm, or DUB spindle cranks into BB386 frames without the need for adapters
Origin8 Nylon composite BB tools are recommended to avoid the possibility of damaging the cups

Shell	Interface	Spindle Type	Cup Material	Weight
86.5mm x 46mm	BB386	SRAM GXP 22/24mm	AL6061/Nylon Fiber	135g

TorqLite UL Rear Chain Guide

Part #: 16270

CHAIN GUIDE OR8 TORQLITE UL

Converts any multi-speed bike to a single speed
Spring loaded design accommodates a wide range of cog sizes
Mounts to frame derailleur hanger
Adjusts for perfect chain tension
Adjustable chainline

Type	Color	Material
Chain Guide	Black	Alloy

Revolvr BB90/95 Thread-Together Bottom Bracket

Part #: 211565

BB SET OR8 REVOLVR BB90/95 TO SHI THREAD TOGETHER SB BK

Replaces standard BB90/95 press in bearings commonly found on Trek bicycles with a solid, unified thread-together bottom bracket interface
Thread-together bottom brackets provide a secure and stable shell interface for smoother operation and extended bearing life
Low-friction dual seals protect the bearings from harmful contaminants
Sealed premium bearings are serviceable
Models available for both Shimano HTII 24mm and SRAM GXP 22/24mm spindles
Requires a special tool for installation (J&B# 610756)

Shell	Interface	Spindle Type	Cup Material	Color
90.5/95.5mm x 37mm	BB90/95	Shimano HTII 24mm	AL6061	Black

Revolvr BB90/95 Thread-Together Bottom Bracket

Part #: 211566

BB SET OR8 REVOLVR BB90/95 TO FIT GXP THREAD TOGETHER SB BK

Replaces standard BB90/95 press in bearings commonly found on Trek bicycles with a solid, unified thread-together bottom bracket interface
Thread-together bottom brackets provide a secure and stable shell interface for smoother operation and extended bearing life
Low-friction dual seals protect the bearings from harmful contaminants
Sealed premium bearings are serviceable
Models available for both Shimano HTII 24mm and SRAM GXP 22/24mm spindles
Requires a special tool for installation (J&B# 610756)

Shell	Interface	Spindle Type	Cup Material	Color
90.5/95.5mm x 37mm	BB90/95	SRAM GXP 22/24mm	AL6061	Black

Revolvr PF30 Outboard Thread-Together Bottom Bracket

Part #: 211567

BB SET OR8 REVOLVR PF30 TO FIT DUB OUTBOARD THREAD TOGETHER SB BK

Thread-together bottom brackets provide a secure and stable shell interface for smoother operation and extended bearing life
Hybrid AL6061/Nylon fiber cups for a superior fit and noise-free operation
Low-friction dual seals protect the bearings from harmful contaminants
Sealed premium bearings are both serviceable and replaceable
Designed for installing Sram DUB 28.99mm spindle cranks into PF30 frames

Shell	Interface	Spindle Type	Cup Material	Weight	Color
68/73mm x 46mm	PF30	SRAM DUB 28.99mm	AL6061/Nylon Fiber	125g	Black

Revolvr BB86/92 OS Thread-Together Bottom Bracket

Part #: 211708

BB SET OR8 REVOLVR BB86/92 TO FIT GXP OS THREAD TOGETHER SB BK

Thread-together bottom brackets provide a secure and stable shell interface for smoother operation and extended bearing life
OS versions are designed for use in frames with worn-out, oversized bottom bracket shells
Hybrid AL6061/Nylon fiber cups for a superior fit and noise free operation
Low-friction dual seals protect the bearings from harmful contaminants
Sealed premium bearings are both serviceable and replaceable
Models available for both Shimano HTII 24mm and SRAM GXP 22/24mm spindles
Replaces all standard BB86/92 press-fit bottom brackets
Origin8 Nylon composite BB tools are recommended to avoid the possibility of damaging the cups

Shell	Interface	Spindle Type	Cup Material	Weight
86-92mm x 41~41.1mm	BB86/BB92	SRAM GXP 22/24mm	AL6061/Nylon Fiber	103g

Revolvr BB86/92 Press-Fit Bottom Bracket

Part #: 211569

BB SET OR8 REVOLVR BB86/92 TO FIT DUB SB BK

Precision machined AL6061 cups for a superior fit and noise-free operation
Low-friction dual seals protect the bearings from harmful contaminants
Sealed dual-row premium flanged bearings
Designed for installing Sram DUB 28.99mm spindle cranks into BB86/92 frames

Shell	Interface	Spindle Type	Cup Material	Weight	Color
86-92mm x 41mm	BB86/BB92	SRAM DUB 28.99mm	AL6061	90g	Black

Revolvr BB86/92 Thread-Together Bottom Bracket

Part #: 211050

BB SET OR8 REVOLVR BB86/92 TO FIT GXP THREAD TOGETHER SB BK

Thread-together bottom brackets provide a secure and stable shell interface for smoother operation and extended bearing life
Hybrid AL6061/Nylon fiber cups for a superior fit and noise-free operation
Low-friction dual seals protect the bearings from harmful contaminants
Sealed premium bearings are both serviceable and replaceable
Models available for both Shimano HTII 24mm and SRAM GXP 22/24mm spindles
Replaces all standard BB86/92 press-fit bottom brackets
Origin8 Nylon composite BB tools are recommended to avoid the possibility of damaging the cups

Shell	Interface	Spindle Type	Cup Material	Weight
86-92mm x 41mm	BB86/BB92	SRAM GXP 22/24mm	AL6061/Nylon Fiber	103g

Revolvr BB86/92 Thread-Together Bottom Bracket

Part #: 211049

BB SET OR8 REVOLVR BB86/92 TO SHI THREAD TOGETHER SB BK

Thread-together bottom brackets provide a secure and stable shell interface for smoother operation and extended bearing life
Hybrid AL6061/Nylon fiber cups for a superior fit and noise-free operation
Low-friction dual seals protect the bearings from harmful contaminants
Sealed premium bearings are both serviceable and replaceable
Models available for both Shimano HTII 24mm and SRAM GXP 22/24mm spindles
Replaces all standard BB86/92 press-fit bottom brackets
Origin8 Nylon composite BB tools are recommended to avoid the possibility of damaging the cups

Shell	Interface	Spindle Type	Cup Material	Weight
86-92mm x 41mm	BB86/BB92	Shimano HTII 24mm	AL6061/Nylon Fiber	103g

Holdfast Oval Direct 1x Chainring GXP

Part #: 210316

CHAINRING OR8 HOLDFAST OVAL DIRECT FOR GXP 34T 10/11/12s BK

Narrow/Wide tooth design for chain retention on 1x systems
Oval shape for increased power and efficiency
13% ovality and 115º clocking
10, 11, or 12 speed compatible
Mud clearing channels
CNC AL7075-T6 Swiss Alloy

Mount Compatibility	Teeth	Type	Material	Spec	Color	Chain Compatibility	Tooth Type
Direct Mount	34T	1x	AL7075	GXP	Black	10/11/12sp	Narrow/Wide

Alloy Crank Set

Part #: 21029

CRANKARM SET OR8 175 110 bcd FORGED SIL

Single/Double crank arm sets
Forged AL6061-T6 crank arms
Includes left and right crank arms only - Does not include chainring(s)
2x Chainline: 44.3mm
Q-Factor: 148.2mm
Does not include square taper BB
Weights do not include BB

Length / Teeth	Spindle Type	Color	Bolt Pattern	Weight	Speed
175mm	107 SQR JIS	SIL	110x5B	510g	1/2

Alloy Crank Set

Part #: 21900

CRANKARM SET OR8 165 110 bcd FORGED BLK

Single/Double crank arm sets
Forged AL6061-T6 crank arms
Includes left and right crank arms only - Does not include chainring(s)
2x Chainline: 44.3mm
Q-Factor: 148.2mm
Does not include square taper BB
Weights do not include BB

Length / Teeth	Spindle Type	Color	Bolt Pattern	Weight	Speed
165mm	107 SQR JIS	BLK	110x5B	510g	1/2

Alloy Crank Set

Part #: 21892

CRANKARM SET OR8 140 110 bcd FORGED BLK

Single/Double crank arm sets
Forged AL6061-T6 crank arms
Includes left and right crank arms only - Does not include chainring(s)
2x Chainline: 44.3mm
Q-Factor: 148.2mm
Does not include square taper BB
Weights do not include BB

Length / Teeth	Spindle Type	Color	Bolt Pattern	Weight	Speed
140mm	107 SQR JIS	BLK	110x5B	510g	1/2

Alloy Crank Set

Part #: 21902

CRANKARM SET OR8 170 110 bcd FORGED BLK

Single/Double crank arm sets
Forged AL6061-T6 crank arms
Includes left and right crank arms only - Does not include chainring(s)
2x Chainline: 44.3mm
Q-Factor: 148.2mm
Does not include square taper BB
Weights do not include BB

Length / Teeth	Spindle Type	Color	Bolt Pattern	Weight	Speed
170mm	107 SQR JIS	BLK	110x5B	510g	1/2

Alloy Crank Set

Part #: 21891

CRANKARM SET OR8 140 110 bcd FORGED SIL

Single/Double crank arm sets
Forged AL6061-T6 crank arms
Includes left and right crank arms only - Does not include chainring(s)
2x Chainline: 44.3mm
Q-Factor: 148.2mm
Does not include square taper BB
Weights do not include BB

Length / Teeth	Spindle Type	Color	Bolt Pattern	Weight	Speed
140mm	107 SQR JIS	SIL	110x5B	510g	1/2

Alloy Crank Set

Part #: 21901

CRANKARM SET OR8 170 110 bcd FORGED SIL

Single/Double crank arm sets
Forged AL6061-T6 crank arms
Includes left and right crank arms only - Does not include chainring(s)
2x Chainline: 44.3mm
Q-Factor: 148.2mm
Does not include square taper BB
Weights do not include BB

Length / Teeth	Spindle Type	Color	Bolt Pattern	Weight	Speed
170mm	107 SQR JIS	SIL	110x5B	510g	1/2

Alloy Crank Set

Part #: 21894

CRANKARM SET OR8 150 110 bcd FORGED BLK

Single/Double crank arm sets
Forged AL6061-T6 crank arms
Includes left and right crank arms only - Does not include chainring(s)
2x Chainline: 44.3mm
Q-Factor: 148.2mm
Does not include square taper BB
Weights do not include BB

Length / Teeth	Spindle Type	Color	Bolt Pattern	Weight	Speed
150mm	107 SQR JIS	BLK	110x5B	510g	1/2

Alloy Crank Set

Part #: 21898

CRANKARM SET OR8 160 110 bcd FORGED BLK

Single/Double crank arm sets
Forged AL6061-T6 crank arms
Includes left and right crank arms only - Does not include chainring(s)
2x Chainline: 44.3mm
Q-Factor: 148.2mm
Does not include square taper BB
Weights do not include BB

Length / Teeth	Spindle Type	Color	Bolt Pattern	Weight	Speed
160mm	107 SQR JIS	BLK	110x5B	510g	1/2

Alloy Crank Set

Part #: 21899

CRANKARM SET OR8 165 110 bcd FORGED SIL

Single/Double crank arm sets
Forged AL6061-T6 crank arms
Includes left and right crank arms only - Does not include chainring(s)
2x Chainline: 44.3mm
Q-Factor: 148.2mm
Does not include square taper BB
Weights do not include BB

Length / Teeth	Spindle Type	Color	Bolt Pattern	Weight	Speed
165mm	107 SQR JIS	SIL	110x5B	510g	1/2

Alloy Crank Set

Part #: 21895

CRANKARM SET OR8 155 110 bcd FORGED SIL

Single/Double crank arm sets
Forged AL6061-T6 crank arms
Includes left and right crank arms only - Does not include chainring(s)
2x Chainline: 44.3mm
Q-Factor: 148.2mm
Does not include square taper BB
Weights do not include BB

Length / Teeth	Spindle Type	Color	Bolt Pattern	Weight	Speed
155mm	107 SQR JIS	SIL	110x5B	510g	1/2

Displaying 251 to 300 (of 1787 products)
